BFW™ Pharos HD™

Product Information

The Only True HD 1080p Coaxial Headlight Imaging System

Pharos HD™ is the only true HD 1080p coaxial headlight imaging system today. Our exclusive coaxial headlight/camera design provides the highest quality video from the surgeon’s point of view – what the surgeon looks at is always in the picture frame without adjusting the camera during a case. Integrated into our AtoN™/Hatteras™ LED fiber optic system, Pharos HD™ provides matchless true 1080p/60 FPS HD imaging. Its lightweight and ergonomic design makes it comfortable, easy to use and unequalled in headlight imaging capture and broadcast.

Pharos HD™ headlight/camera available with our Classic Fiji™ headband.

Pharos™ System Includes

  • Pharos™ HD Headlight Camera Unit with 10’ (Approx. 3m) Fiber Optic Cable
  • Hatteras™ LED High-Intensity Light Source
  • Pharos™ HD Camera Control Unit
  • Video Cables and Power Cords
  • Mobile Stand
  • Keyboard for Patient Info Input Available as Accessory


  • 1080p/60 FPS Video Output – Camera Chip – CMOS Digital
  • 1920 x 1080 True HD
  • Focal Distance – Adjustable 10-to-24” (25.4-to-61 cm)
  • Digital Zoom –Up to 16X Magnification
  • Push-Button Membrane Controls
  • Image Stabilization Setting
  • White Balance, Brightness, Sharpness and Zoom
  • Custom Locking Camera Input to CCU
  • 1 SDI output, 1 HDMI output
  • Compatible with Most HD or Integrated OR Theater HD Recording Systems
  • 4.5” Diameter spot at 16” working distance
  • 1-Year Limited Manufacturer’s Warranty

Safety, Regulatory Compliance

  • IEC 60601-1 (ed. 3)
  • IEC 60601-1-2 (ed. 4)
  • ANSI/AAMI ES60601-1 (2005 + C1:09 + A2:10)
  • CAN/CSA-C22.2 NO. 60601-1-(2008)
  • CE

Durable flexible cushioning.  Cured silicone elastomer.  Blue, radio-opaque silicone.

  • Used in oral surgery
  • Protect the teeth, caps & crowns from accidental damage or trauma
  • High tear-resistance & tensile strength
  • Adult & child sizes
  • Sterile or non-sterile
